FR-4/TG135 Security Camera PCB: Built for Reliability, Engineered for Clarity
At PCBLOOP, we understand the critical role security camera PCBs play in safeguarding your assets and ensuring peace of mind. That’s why we specialize in crafting high-performance FR-4/TG135 Security Camera PCBs that deliver exceptional reliability and performance, exceeding industry standards.



Why Choose Our FR-4/TG135 Security Camera PCBs?

Uncompromising Durability: We utilize premium FR-4 and TG135 materials, ensuring robust electrical performance, thermal stability, and mechanical strength. These PCBs are built to withstand demanding environments and deliver consistent performance, even in challenging conditions.

Precision Engineering: Our state-of-the-art manufacturing processes ensure the highest precision, utilizing advanced etching, plating, and lamination techniques to achieve tight tolerances and exceptional electrical performance. This translates to clearer images, faster processing, and reliable operation.

Tailored Solutions: We understand that every security camera has unique requirements. Our team of engineers is dedicated to providing customized solutions that perfectly match your specific design specifications, ensuring seamless integration and optimal performance for your security camera system.

Quality Assurance: We are committed to delivering exceptional quality. Our production processes are rigorously tested and certified to ISO 9001 standards, ensuring consistent reliability and performance for your security camera PCBs.
Partner with Us for Unwavering Security:

Industry Expertise: We have extensive experience in manufacturing FR-4/TG135 Security Camera PCBs for diverse applications. Our team possesses in-depth knowledge of PCB technology and security camera design, allowing us to deliver solutions that meet your unique needs.

Dedicated Support: We are here to support you every step of the way. Our dedicated team provides comprehensive technical support, ensuring a smooth implementation and ongoing maintenance of your security camera solution.
Contact us today to discuss your FR-4/TG135 Security Camera PCB needs and let us help you build a security system that delivers clarity and reliability.



Technical Capability:

Technical Factors	Descriptions
Application	Electronics Device, Consumer Electronics, Electronical products, Industrial, and so on
Number of layers	2/4/6/8/10/12 Layers, 1-20 Layers, Other
Type	Rigid, Flex, Flex-Rigid
Copper thickness	1oz, 0.5-2.0 oz, 1oz~3oz,
Base material	FR4, (High TG), Aluminium, Rogers, CEM-1
Board thickness	0.6~2.5mm
Min. line width	4mil, 0.1mm, 0.1mm(Flash Gold)/0.15mm(HASL)
Min. line spacing	0.1mm, 4mil
Min. hole size	0.15mm,6mil
Surface finishing	OSP, ENIG, HASL Lead Free, immersion gold
Solder mask	Blue, Green,Red,White,Black,Yellow,Purple
Testing	Flying Probe, ICT
Advanced Process	B/B Vias, Controlled Impedance, HDI,etc.







PCB Specifications:

Feature	Description
Base Material	FR4-TG135
Layer Count	4layers
Dielectric Constant	4.3
Board Thickness	1.6 mm
Outer Layer Copper Thickness	1 OZ
Inner Layer Copper Thickness	1 OZ
Surface Finish	ENIG
Minimum Hole Diameter	0.25mm
Minimum Trace Width	0.127mm
Minimum Trace Spacing	0.127mm
Application	Security Surveillance
Features	Black Oil Via Plug
