HDI With Blind vias/Buried vias PCB Manufacturing with 0.075mm Trace Space
Product Description:
HDI with Blind/Buried Vias PCB Manufacturing: Unlocking the Potential of High-Density Interconnect
At PCBLOOP, we specialize in crafting high-performance HDI PCBs with blind and buried vias, pushing the boundaries of electronic design. Our commitment to precision and quality ensures that your complex electronic devices achieve the performance and reliability they demand.
Why Choose HDI with Blind/Buried Vias?
Unmatched Density: HDI technology with blind and buried vias allows for a significantly higher component density on your PCB, enabling smaller form factors and more complex designs.
Enhanced Signal Integrity: Blind and buried vias minimize signal path lengths, reducing signal distortion and crosstalk, leading to improved performance and reliability.
Flexibility in Design: Blind and buried vias provide greater flexibility in routing, allowing for complex signal paths and efficient component placement.
Our Expertise:
Advanced Manufacturing: We utilize state-of-the-art equipment and processes to produce HDI PCBs with precise dimensions and thickness ranging from 0.6mm to 2.5mm, ensuring consistent quality and reliability.
Experienced Engineers: Our team of engineers is dedicated to providing customized solutions that meet your unique design requirements, ensuring seamless integration and optimal performance.
Flexible Logistics: We offer a range of logistics options, including customer-specified logistics, ensuring timely delivery of your HDI PCBs in perfect condition.
Partner with us to unlock the full potential of your electronic designs. Contact us today to discuss your HDI PCB with blind and buried vias needs and let us help you build a product that excels.
PCB Specifications:
| Feature | Description |
| Base Material | FR-4/TG160 |
| Layer Count | 6 layers |
| Dielectric Constant | 4.2 |
| Board Thickness | 1.6 mm |
| Outer Layer Copper Thickness | 1.5 OZ |
| Inner Layer Copper Thickness | 1 OZ |
| Surface Finish | ENIG |
| Minimum Hole Diameter | 0.2mm |
| Minimum Trace Width | 0.1mm |
| Minimum Trace Spacing | 0.075mm |
| Application | Industrial Control |
| Features | Blind vias
Buried vias Controlled Impedance Via Plug |
